PRESSURE RATIO | 2.25:1 (@ 7 bar air – 15.7 bar product) |
MAXIMUM FLUID PRESSURE | 22.5 bar |
MAXIMUM AIR INLET PRESSURE | 10 bar |
MAXIMUM FLUID TEMPERATURE | 85ºC |
MAXIMUM OUTLET VOLUME | 20.8L./min |
PISTON MOVEMENT | 101.6mm (4”) |
SUCTION VOLUME (ONLY RISING) | 206cm3 |
TRANSFER VOLUME (BY STROKE/CYCLE) | 103cm3/206cm3 |
VOLUME OF CONSUMED AIR (BY STROKE/CYCLE) @ 7 BAR | 1.6L/3.2L |
N.CYCLES TO TRANSFER 1 LITRE | 4.85 |
WEIGHT | 10.5Kg (23.15lb) |
AIR CONNECTION | 1/4”NPT |
PRODUCT OUTLET CONNECTION | 3/4”NPT |
NOISE LEVEL @ 7 BAR (AIR) | 85 (A) dB |
